HD Series High Frequency Online UPS

This is a straightforward UPS for everyday gear. Nothing fancy, but it covers the things you actually need.

It charges even when the UPS is turned off—just plug it in, and the battery tops up. That’s handy if you only use the UPS occasionally or want it ready before you switch it on.

Appurtenance:

Key Features
Technical Specification
Product Description
Related Products

Key Features

·Off-mode Charging

·Supports 110VAC/220VAC voltage input

·LED Display

·At half-charge,the standby time can reach 4 minutes.

·USB Output:5V/2A*2 pcs

Technical Specification

Model	HD 600	HD-LV 600	HD 1000	HD-LV 1000
Rated Power	600VA/360W		1000VA/500W
Power Factor	0.6		0.5
BATTERY
Discharge Time	300 watts for 4 minutes
Battery Capacity	12V 4.5Ah Lead acid battery		12V 5Ah Lead acid battery
Recharge Time	8 hours
INPUT
AC Input Voltage	220VAC	110VAC	220VAC	110VAC
AC Input Voltage Range	175-260VAC	90-130VAC	175-260VAC	90-130VAC
AC Input Frequency	50 /60Hz
OUTPUT
AC Output Voltage Range	90-130VAC	90-130VAC	90-130VAC	90-130VAC
AC Output Voltage(Battery Mode)	225±5VAC	115±5VAC	225±5VAC	115±5VAC
AC Output Frequency	50/60Hz
Output Waveform	PWM(batt.mode)
USB Output	5V/2A*2
Output Sockets	4x European or 8×American standard backup socket or bypass for option
ENVIRONMENT
Environment of Performance	Temperature 0℃-40℃,Humidity 20%-90%
Noise Level	≤40dB(1m)
MACHINE SPECIFICATIONS
Dimension (LWH)(mm)	257170108
Net Weight(Kg)	3
*Product Specifications are Subject to Change Without Notice.

Product Description

This is a straightforward UPS for everyday gear. Nothing fancy, but it covers the things you actually need.

It charges even when the UPS is turned off—just plug it in, and the battery tops up. That’s handy if you only use the UPS occasionally or want it ready before you switch it on.

Works with both 110V and 220V inputs. So whether you’re in a country that runs on lower voltage or higher, the same unit fits—no need to stock different versions.

The display is a simple LED. It won’t give you graphs or menus, but it tells you power status at a glance. Sometimes that’s all you want.

At half load, you get about 4 minutes of backup time. That’s not for running a server farm, but it’s plenty to save your work, shut down a computer, or keep a POS terminal from crashing during a quick blip.

Two USB ports on the front, each putting out 5V/2A. That’s enough to charge a phone, tablet, or small accessory even when the main power is out. A small touch, but surprisingly useful when the lights go off and your phone is at 5%.

In short, it’s a no-drama UPS for desks, retail counters, or small network setups where you want basic protection without overpaying for features you’ll never use.
