Sun Star Series High Frequency Online UPS

Sun Star Series High Frequency Online UPS

-This one’s built differently. It’s a true online double-conversion UPS, so your equipment never actually runs on raw utility power. Instead, it continuously regenerates clean, pure sine wave output — no sags, no spikes, no switching delays.

Appurtenance:

sun star series high frequency online ups-0

Key Features
Technical Specification
Product Description
Related Products

Key Features

·Double Conversion True Online UPS With Pure Sine-Wave Output

·Robust Design,Conformal Coating,Strong

Anti-Corrosion Capability For Harsh Environment

·Extra Wide Input Voltage (90V-300Vac), WellCompatible With Gen-Set

·Input Power Factor Correction,Save Power, Wiring Expense For Use

·Strong Loading Capability,Work Well With Laser Printer,Ultrasonic Cleaner

·Compact Size,Win Valuable Space For User

·Open For Customization,Seamless Integrate With Automatic Control System

Technical Specification

Tower Model	S1K S1KL		S2K S2KL		S3K S3KL S6K S6KL S10K S10KL
Phase	Single phase (L/N+PE)
Capacity	1KVA/900W		2KVA/1.8KW		3KVA/2.7KW		6KVA/54KW		10KVA/9KW
Input
Nominal lnput Voltage	208/220/230/240Vac
Input Voltage Range	90~300VAC±5VAC
Frequency	50/60 Hz
Input Frequency Range	40~70Hz
Input Power Factor	>0.99
Bypass Voltage Range	180～265VAC*(1±3%)
Output
Output wiring system	Single phase(L/N+PE)
Output Voltage	208/220/230/240Vac±2%
Output Voltage Regulation	1%
Output Frequency	50/60±4Hz (Sync mode);50/60Hz±1%(Fix Freq.mode)
Overload Capability	105~125%≥60s,126~150%≥30s The recover point is 70%
Output THDV%	THD<2%(linear load);THD<7%(nonlinear load)
Output Waveform	Pure Sine Wave
Transfer Time
Line mode→Bat Mode	Oms
Inv→Bypass Mode	<4ms
Efficiency
Line Mode	86%		88%		89%		92%		93%
Battery Mode	85%		86%		87%		92%		93%
Battery &Chager
Nominal Voltage	24V	24V/36V	48V	48V/72V	72V	72V/96V	144V/192V	192V/240V	192V/240V
Battery Voltage /Capacity	2*12V/7AH	External Battery	4*12V/7AH	External Battery	6*12V/7AH	Externa Battery	12/16*12V/7AH	External Battery	16/20*12V/7AH	192V/240V External Battery
Battery Type	Valve Regulated Maintenance Free Lead Acid (VRLA)for Standard Model with Internal Battey
Backup Time	Half loaded≥8minutes,Full loaded≥3minutes(standard)						Half loaded≥6minutes,Full loaded≥3minutes(standard)
Recharge Time	~5 Hours	Subject to External Battery Config	~5 Hours	Subject to Externa Battery Config	~5 Hours	Subject to External Battery Config	~5 Hours	Subject to External Battery Config	~5 Hours	Subject to External Battery Config
Recharge Curent	1A	4A	1A	4A	1A	4A	1A	4A	1A	4A
HMI
Display	LCD
Buzzer Alarm	Bat.Mode/Bat.Low/OverLoad/Fault
Communication Port	Standard:RS232+EPO/ROO+USB PORT;SNMP Card Slot (Option)
Alarm Function	AC/DC input under abnormal,overload condition and Inverter problems
Protection Function	ACinput or output above or below the range of voltage,overload,over temperature and short circuit protection
Physical
Machine Size-W*D^H(mm)	144349224		190368323		190368323		190566472	190399323	190562340	190562340
Package Size-W*D'H(mm)	243458312		295460435		295460435		335670665	295460435	335670665	290625430
Net Weight(KG)	8.4	4.5	16	6	20.7	7.7	48.3	9.9	50.1	13.5
Gross Weight(KG)	9.5	5.6	17.4	7	22	9.5	55	11.4	56.8	15.2
Environment
Humidity	5~97%(Non Condensing)
Operating Ambient Temperature	0~40℃
Audible Noise	<50dB						<55dB
*External Battery Pack Rated Voltage Can Select Upon Order,192/240V
*Product Specifications are Subject to Change Without Notice.

Product Description

-If your setup lives in a less-than-friendly environment — think dust, humidity, or industrial conditions — the conformal coating on the internal boards adds a layer of protection against corrosion. It’s the kind of durability you want when the UPS isn’t sitting in a climate-controlled office.

-Input voltage range is wide: 90V to 300Vac. That means it keeps running even when grid power gets ugly, and it plays nicely with generators — no constant switching back and forth when the genny stumbles.

-It also comes with input power factor correction. In plain terms, it uses less current from the wall to deliver the same power, which can save you a bit on wiring costs if you’re running multiple units or working with limited circuit capacity.

-Load handling is strong. This UPS can comfortably power laser printers and ultrasonic cleaners — gear that tends to trip up regular UPS units because of their sharp power draws.

-The chassis is compact, so it doesn’t eat up valuable rack or floor space. And if you need to integrate it with an automatic control system—like a building management or industrial automation setup — there’s room for customization to make that connection seamless.
